TQF- 568 Rotor Spinning Machine

TQF- -568 rotor spinning machine is a kind of new-type open end spinning machine with some features such as high speed, high efficiency, automatic exhausting impurities. It can spin directly various short fibers, 40mm cut fibers or 60mm cut viscose into single fine yarn from combed sliver.

This is a double - side -type spinning machine based on modularized design. It applies many new technologies such as air suction spinbox, semi-automatic piecing-in, closed loop control etc. Max. rotor speed can reach 110000rpm.

Thanks to application of numerous new technologies, it holds spinning and winding quality close to full automatic rotor spinning machine, and then shows better price- performance ratio.

Spinbox

Spinning components

T-ic intelligent convenient piecing-in system

Winding mechanism

Electrical control system on machine body

Yarn guide traverse mechanism

Micro-tension mechanism

Main drive

Electrical cabinet design with patent

Waxing device

Top travelling cleaner

Electronic yarn clearer

More flexible spinning functions

Convenient refueling or automatic refueling device

Joint Spinning-in

Spinbox

Novel structure: change of spinning components without any tools, convenient operation.
Single step-motor drive sliver intake: enable sliver to realize variable speed feeding.
Adjustable exhausting impurities channel: reasonable adjustment according to different material, efficient control of exhausting impurities percentage.
Air suction type spinning rotor: various rotors can be applied, min. rotor diameter is 32mm, max. rotor speed is 110000 rpm.

Spinning components

Permit to select different spinning components according to different technologic requirements. Wider application range and lower operation cost thanks to series and standardization of spinning components.

T-ic intelligent convenient piecing-in system

Semi-automatic operation, intelligent control; automatically finish piecing-in operation of yarn if only close spinbox. Variable speed sliver feeding and reversing, millisecond -level control, perfect piecing quality of yarn. Easy operation, higher stability and piecing-in success rate.

Winding mechanism

Package lift-off device: when the package is full or a yarn break occurs, the package will be lifted immediately and departed from winding roller.
New type tapered winding form: Winding roller for tapered package is divided into left and right part on which the speeds can be automatically adjusted, thus enable tapered package to realize double-support winding.
Novel bobbin cradle structure: This structure can ensure yarn tension uniform inside and outside take-up package; permit to spin yarn continually when doffing and to reserve the tailing formation.

Electrical control system on machine body

Novel electrical control system on machine body:
So easy operation and maintenance, faster communication, stronger anti-interference.

Yarn guide traverse mechanism

Novel electronic yarn guide traverse:
Adopting the advanced servo drive system;
Independent control per side, more convenient operation and maintenance;
More perfect formation of package.

Micro-tension mechanism

Span-new inverter control function;
moderately adjust yarn tension and winding angle;
Easy to operate.

Main drive

reduce vibration of machine;
Constantly increase speed for rotor and combing roller; controllable for piecing time.

Electrical cabinet design with patent

More reasonable layout for electrical components, more convenient operation and maintenance, with a circulation ventilation system for fast cooling inverter and getting longer life of inverter.

Waxing device

Drive the waxing shaft by a friction drive disc, then drive the waxing roll to realize waxing of yarn

Top travelling cleaner

Remarks: Optional

Electronic yarn clearer

A standard terminal is reserved on the control system of machine; various electronic yarn clearers can be installed at any moment.

More flexible spinning functions

Equipped with the function for spinning fancy yarns and two different kinds of yarns can be spin at same time on two sides of the machine, which makes it more flexible so as to have a better use of space.
